FK-JL6 Carbonated Drink Filling Machine for Glass Packaging Material and 20 bots/min

Ask Lasest Price
Brand Name :	FK-SPEEDA
Certification :	ISO9001
Supply Ability :	1000 Set/Sets per Month
Price :	$13,000.00/sets 1-2 sets

Add to Cart

Product Details
Company Profile

FK-JL6 Carbonated Drink Filling Machine for Glass Packaging Material and 20 bots/min

Product Overview

Features:

The production line can widely used to filling,capping and labeling for various semi-liquid,ointment paste, dense catsup and various materials with granule, such as drinks with fruit, honey,syrup,jam, peanut butter, sesame paste,tomato sauce, peper sauce,etc.Operating principle By the reciprocating motion of the pistons in the material cylinders of the Filling Machine, negative pressure produces in the front chamber of the cylinder so that material could be pumped. The stroke of the cylinder is controlled by a signal valve so as to adjust filing amount and to achieve accurate filling results.Property The Filling Machine with extra functions is designed and manufactured by our factory with reference to the same kind of foreign machines.
This machine is simpler and easier in operation, error correction, adjustment, cleaning and maintenance.With automatic
transmission, automatic filling, no bottle no filling, bottle positioning, prevent drip, lifting filling, and other functions. Can
be equipped with protective cover.The part contacting materials is made of 304 stainless steel.Material contact parts can be customized SS316.can install hopper. Hopper can be installed liquid level automatic control system.

Optional Configuration

1. conveyer; 2. CIP tank; 3. mix tank; 4. double jacket tank; 5. Plexiglass

Application

PRODUCT SPECIFICATIONS

Model	FK-JL6
Filling range	20-100ml,50-200ml,100-600ml,300-1000ml,500-2000ml
Filling speed	30~50 bottles per minute
Power	220V/50Hz 200W
Filling accuracy	Above(within):±1.5%
Air Pressure	0.4-0.6Mpa

PRODUCT CONFIGURATION

Guangdong Fineco Machinery Group Co., Ltd

Guangdong Fineco Machinery Group Co.,Ltd. is a professional large-scale manufacturer of packaging machine,Integrating development and production together, Our main products include High-accuracy labeling machine, filling machine,capping machine,shrinkage machine, self-adhesive labeling machine and related equipment. Located in Chang'an Town, Dongguan City,Guangdong Province,China. we enjoy convenient land and air transportation.And with offices in Jiangsu Province, Shangdong Province,Fujian Province and other regions.

Currently,Fineco is already exported to America,France,Australia,Germany and 50 other countries and regions. Our company has always focused on research,development and innovation,has obtained a number of patent certificates,and be rated as Chinese "Hight and New Technology Enterprise'in 2017 .we also attained ISO9001 and CE certifications.

Fineco regards "Reasonable Prices,Efficient Production and Good After-sales Service "as our tenet.We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.
